FP7G100US60
Fairchild Semiconductor
Package: Tube
Description: IGBT, 100A, 600V, N-CHANNEL
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Input | Standard |
|---|---|
| IGBT Type | - |
| Part Status | Obsolete |
| Power - Max | 400 W |
| Configuration | Half Bridge |
| Mounting Type | Chassis Mount |
| NTC Thermistor | No |
| Package / Case | EPM7 |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Supplier Device Package | EPM7 |
| Vce(on) (Max) @ Vge, Ic | 2.8V @ 15V, 100A |
| Current - Collector (Ic) (Max) | 100 A |
| Input Capacitance (Cies) @ Vce | 6.085 nF @ 30 V |
| Current - Collector Cutoff (Max) | 250 μA |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
