FF3MR12KM1HPHPSA1
Infineon Technologies
Package: Box
Description: MOSFET 2N-CH 1200V 220A AG62MMHB
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Technology | Silicon Carbide (SiC) |
| FET Feature | - |
| Part Status | Active |
| Power - Max | - |
| Configuration | 2 N-Channel (Half Bridge) |
| Mounting Type | Chassis Mount |
| Qualification | - |
| Package / Case | Module |
| Vgs(th) (Max) @ Id | 5.1V @ 112mA |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Rds On (Max) @ Id, Vgs | 4.44mOhm @ 280A, 18V |
| Supplier Device Package | AG-62MMHB |
| Gate Charge (Qg) (Max) @ Vgs | 800nC @ 18V |
| Drain to Source Voltage (Vdss) | 1200V (1.2kV) |
| Input Capacitance (Ciss) (Max) @ Vds | 24200pF @ 800V |
| Current - Continuous Drain (Id) @ 25°C | 220A |
