DTA124XEBTL
ROHM Semiconductor
Package: Cut Tape (CT)
Description: TRANS PREBIAS PNP 50V 0.1A EMT3F
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Part Status | Active |
|---|---|
| Power - Max | 150 mW |
| Mounting Type | Surface Mount |
| Package / Case | SC-89, SOT-490 |
| Transistor Type | PNP - Pre-Biased |
| Resistors Included | R1 and R2 |
| Resistor - Base (R1) | 22 kOhms |
| Frequency - Transition | 250 MHz |
| Supplier Device Package | EMT3F (SOT-416FL) |
| Resistor - Emitter Base (R2) | 47 kOhms |
| Vce Saturation (Max) @ Ib, Ic | 300mV @ 500μA, 10mA |
| Current - Collector (Ic) (Max) | 100 mA |
| Current - Collector Cutoff (Max) | 500nA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 68 @ 5mA, 5V |
| Voltage - Collector Emitter Breakdown (Max) | 50 V |
