DFA50BA160
SanRex Corporation
Package: Tray
Description: SCR MODULE 1.6KV MODULE
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Structure | Bridge, 3-Phase - SCRs/Diodes |
|---|---|
| Part Status | Active |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Voltage - Off State | 1.6 kV |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Number of SCRs, Diodes | 1 SCR, 6 Diodes |
| Current - Gate Trigger (Igt) (Max) | 70 mA |
| Current - On State (It (AV)) (Max) | 50 A |
| Voltage - Gate Trigger (Vgt) (Max) | 3 V |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 730A, 800A |
