CM5160 PBFREE
Central Semiconductor Corp
Package: Bulk
Description: RF TRANS PNP 40V 500MHZ TO-39
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Gain | - |
|---|---|
| Part Status | Obsolete |
| Power - Max | 1W |
| Mounting Type | Through Hole |
| Package / Case | TO-205AD, TO-39-3 Metal Can |
| Transistor Type | PNP |
| Operating Temperature | -65°C ~ 200°C (TJ) |
| Frequency - Transition | 500MHz |
| Supplier Device Package | TO-39 |
| Noise Figure (dB Typ @ f) | - |
| Current - Collector (Ic) (Max) | 400mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 10 @ 50mA, 5V |
| Voltage - Collector Emitter Breakdown (Max) | 40V |
