BT151X-650LTNQ
WeEn Semiconductors
Package: Tube
Description: SCR 650V 12A TO220F
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| SCR Type | Sensitive Gate |
|---|---|
| Part Status | Active |
| Mounting Type | Through Hole |
| Package / Case | TO-220-3 Full Pack, Isolated Tab |
| Voltage - Off State | 650 V |
| Operating Temperature | 150°C (TJ) |
| Supplier Device Package | TO-220F |
| Current - Hold (Ih) (Max) | 20 mA |
| Current - Off State (Max) | 1 mA |
| Voltage - On State (Vtm) (Max) | 1.5 V |
| Current - Gate Trigger (Igt) (Max) | 5 mA |
| Current - On State (It (AV)) (Max) | 7.5 A |
| Voltage - Gate Trigger (Vgt) (Max) | 1 V |
| Current - On State (It (RMS)) (Max) | 12 A |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 120A, 132A |
