BFU530R
NXP USA Inc.
Package: Cut Tape (CT)
Description: RF TRANS NPN 12V 11GHZ SOT-143B
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Gain | 21.5dB |
|---|---|
| Grade | Automotive |
| Part Status | Last Time Buy |
| Power - Max | 450mW |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q101 |
| Package / Case | TO-253-4, TO-253AA |
| Transistor Type | NPN |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Frequency - Transition | 11GHz |
| Supplier Device Package | SOT-143B |
| Noise Figure (dB Typ @ f) | 0.6dB @ 900MHz |
| Current - Collector (Ic) (Max) | 40mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 60 @ 10mA, 8V |
| Voltage - Collector Emitter Breakdown (Max) | 12V |
