BFG505/X,215
NXP Semiconductors
Package: Bulk
Description: RF TRANS NPN 15V 9GHZ SOT-143B
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Gain | - |
|---|---|
| Part Status | Obsolete |
| Power - Max | 150mW |
| Mounting Type | Surface Mount |
| Package / Case | TO-253-4, TO-253AA |
| Transistor Type | NPN |
| Operating Temperature | 175°C (TJ) |
| Frequency - Transition | 9GHz |
| Supplier Device Package | SOT-143B |
| Noise Figure (dB Typ @ f) | 1.2dB ~ 1.9dB @ 900MHz ~ 2GHz |
| Current - Collector (Ic) (Max) | 18mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 60 @ 5mA, 6V |
| Voltage - Collector Emitter Breakdown (Max) | 15V |
