AOB30B65LN2V
Alpha & Omega Semiconductor Inc.
Package: Tape & Reel (TR)
Description: IGBT 650V 60A TO-263
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| IGBT Type | - |
|---|---|
| Input Type | Standard |
| Gate Charge | 52 nC |
| Part Status | Active |
| Power - Max | 227 W |
| Mounting Type | Surface Mount |
| Package / Case | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB |
| Test Condition | 400V, 30A, 10Ohm, 15V |
| Switching Energy | 880μJ (on), 350μJ (off) |
| Td (on/off) @ 25°C | 23ns/109ns |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Supplier Device Package | TO-263 (D2PAK) |
| Vce(on) (Max) @ Vge, Ic | 2.35V @ 15V, 30A |
| Reverse Recovery Time (trr) | 312 ns |
| Current - Collector (Ic) (Max) | 60 A |
| Current - Collector Pulsed (Icm) | 90 A |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
