3P4J-ZK-E1-AZ
Renesas Electronics Corporation
Package: Bulk
Description: SILICON CONTROLLED RECTIFIER
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| SCR Type | Standard Recovery |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Voltage - Off State | 500 V |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Supplier Device Package | TO-252 ( MP-3Z) |
| Current - Hold (Ih) (Max) | 5 mA |
| Current - Off State (Max) | 50 μA |
| Voltage - On State (Vtm) (Max) | 1.4 V |
| Current - Gate Trigger (Igt) (Max) | 100 μA |
| Current - On State (It (AV)) (Max) | 3 A |
| Voltage - Gate Trigger (Vgt) (Max) | 800 mV |
| Current - On State (It (RMS)) (Max) | 4 A |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 40A @ 50Hz |
