2SC5196
EVVO
Package: Tube
Description: TRANS NPN 80V 6A TO-3PS
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Part Status | Active |
| Power - Max | 60 W |
| Mounting Type | Through Hole |
| Qualification | - |
| Package / Case | TO-3P-3, SC-65-3 |
| Transistor Type | NPN |
| Operating Temperature | 150°C (TJ) |
| Frequency - Transition | 30MHz |
| Supplier Device Package | TO-3PS |
| Vce Saturation (Max) @ Ib, Ic | 2V @ 500mA, 5A |
| Current - Collector (Ic) (Max) | 6 A |
| Current - Collector Cutoff (Max) | 5μA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 55 @ 1A, 5V |
| Voltage - Collector Emitter Breakdown (Max) | 80 V |
