2SC5095-O(TE85L,F)
Toshiba Semiconductor and Storage
Package: Tape & Reel (TR)
Description: RF TRANS NPN 10V 10GHZ SC-70
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Gain | 13dB ~ 7dB |
|---|---|
| Part Status | Obsolete |
| Power - Max | 100mW |
| Mounting Type | Surface Mount |
| Package / Case | SC-70, SOT-323 |
| Transistor Type | NPN |
| Operating Temperature | 125°C (TJ) |
| Frequency - Transition | 10GHz |
| Supplier Device Package | SC-70 |
| Noise Figure (dB Typ @ f) | 1.8dB @ 2GHz |
| Current - Collector (Ic) (Max) | 15mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 80 @ 7mA, 6V |
| Voltage - Collector Emitter Breakdown (Max) | 10V |
