2SC4536-T1-AZ
CEL
Package: Tape & Reel (TR)
Description: RF TRANS NPN 15V 5.5GHZ SOT-89
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Gain | 7dB |
|---|---|
| Part Status | Obsolete |
| Power - Max | 2W |
| Mounting Type | Surface Mount |
| Package / Case | TO-243AA |
| Transistor Type | NPN |
| Operating Temperature | 150°C (TJ) |
| Frequency - Transition | 5.5GHz |
| Supplier Device Package | SOT-89 |
| Noise Figure (dB Typ @ f) | 2dB @ 1GHz |
| Current - Collector (Ic) (Max) | 250mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 40 @ 50mA, 10V |
| Voltage - Collector Emitter Breakdown (Max) | 15V |
