2SC4308TZ-E
Renesas Electronics Corporation
Package: Bulk
Description: RF TRANS NPN 20V 2.5GHZ TO-92
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Gain | - |
|---|---|
| Grade | - |
| Part Status | Active |
| Power - Max | 600mW |
| Mounting Type | Through Hole |
| Qualification | - |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) |
| Transistor Type | NPN |
| Operating Temperature | 150°C (TJ) |
| Frequency - Transition | 2.5GHz |
| Supplier Device Package | TO-92 |
| Noise Figure (dB Typ @ f) | - |
| Current - Collector (Ic) (Max) | 300mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 50 @ 50mA, 5V |
| Voltage - Collector Emitter Breakdown (Max) | 20V |
