2SC4228-A
CEL
Package: Strip
Description: RF TRANS NPN 10V 8GHZ SC-70-3
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Gain | 7.5dB |
|---|---|
| Part Status | Obsolete |
| Power - Max | 150mW |
| Mounting Type | Surface Mount |
| Package / Case | SC-70, SOT-323 |
| Transistor Type | NPN |
| Operating Temperature | 150°C (TJ) |
| Frequency - Transition | 8GHz |
| Supplier Device Package | SC-70-3 |
| Noise Figure (dB Typ @ f) | 1.9dB @ 2GHz |
| Current - Collector (Ic) (Max) | 35mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 50 @ 5mA, 3V |
| Voltage - Collector Emitter Breakdown (Max) | 10V |
