2N6283 PBFREE
Central Semiconductor Corp
Package: Tube
Description: 20A 80V TH TRANSISTOR-BIPOLAR PO
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Part Status | Active |
|---|---|
| Power - Max | 160 W |
| Mounting Type | Through Hole |
| Package / Case | TO-204AA, TO-3 |
| Transistor Type | NPN - Darlington |
| Operating Temperature | -65°C ~ 200°C (TJ) |
| Frequency - Transition | 4MHz |
| Supplier Device Package | TO-3 |
| Vce Saturation (Max) @ Ib, Ic | 2V @ 40mA, 10A |
| Current - Collector (Ic) (Max) | 20 A |
| Current - Collector Cutoff (Max) | 1mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 1250 @ 10A, 3V |
| Voltage - Collector Emitter Breakdown (Max) | 80 V |
