2N5323 PBFREE
Central Semiconductor Corp
Package: Box
Description: 50V 2A 10W TH TRANSISTOR-BIPOLAR
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Part Status | Active |
| Power - Max | 10 W |
| Mounting Type | Through Hole |
| Qualification | - |
| Package / Case | TO-205AD, TO-39-3 Metal Can |
| Transistor Type | PNP |
| Operating Temperature | -65°C ~ 200°C (TJ) |
| Frequency - Transition | 50MHz |
| Supplier Device Package | TO-39 |
| Vce Saturation (Max) @ Ib, Ic | 1.2V @ 50mA, 500mA |
| Current - Collector (Ic) (Max) | 2 A |
| Current - Collector Cutoff (Max) | 500μA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 40 @ 500mA, 4V |
| Voltage - Collector Emitter Breakdown (Max) | 50 V |
